CY-S Normal temperature Overflow Dyeing Machine use overflow nozzle with lowest pressure(min0.2bar),can reduce fabric tensions,pilling and yarn sliding,cooperate with overflowing cloth tube increase fabric dipping moisture penetration time , even dyeing, crease improve the dyeing quality.
Product Introduction
We always focus on manufacturing quality Warp Yarn Beam Dyeing Machine, HTHP Overflow Dyeing Machine, HTHP Yarn Package Dyeing Machine, providing quality services for customers and creating value for society. Our company always takes the high quality as the leading, takes the continuous improvement as the goal, devotes in the intense market competition. On the road of future development, we will continue to explore and innovate technologies, and continuously improve product quality and service levels. We focus on improving efficiency and vitality, and make every effort to strengthen reform and management.
Introduction
CY-S Normal temperature Overflow Dyeing Machine use overflow nozzle with lowest pressure(min0.2bar),can reduce fabric tensions,pilling and yarn sliding,cooperate with overflowing cloth tube increase fabric dipping moisture penetration time , even dyeing, crease improve the dyeing quality.

Product Characteristics
Low bath ratio
High running speed
Fast dyeing system
Low tension,full flow pipe saturate device
Multi-function fabric vibration system
Special forming collector &fast rinsing system
Easily operation &Full automatic or manual control

Work Principle and Main Parts

1.Drive roll | 2.Vortex nozzle |
3.Inner swing cloth device | 4.Fabric |
5.Overflow washing water valve | 6.Water inlet valve |
7.Water drain valve | 8.Heating valve |
9.Cooling valve | 10.Steam trap |
11.Drain cooling water valve | 12.Dyeing liquid return valve |
13.Feeding intake valve | 14.Main circulation pump |
15.Charging valve | 16.Charging sewage valve |
Technical Data
Item | CY-1 200 | CY-2 400 | CY-4 800 | CY-6 1200 | CY-8 1600 | CY-10 2000 | CY-12 2400 | |
Max temp | 98℃ | |||||||
Liquid Lit | 600-1200 | 1200-2400 | 2400-4800 | 3600-7200 | 4800-9600 | 6000-12000 | 7200-14400 | |
Capacity kg | 160-200 | 320-400 | 640-800 | 960-1200 | 1280-1600 | 1600-2000 | 1920-2400 | |
Main pump HP | 7.5 | 15 | 30 | 50 | 60 | 75 | 100 | |
Heating rate | 20 | |||||||
Cooling rate | 15 | |||||||
Fabric speed | 450 | |||||||
Steam kg/cycle | 173 | 346 | 692 | 1038 | 1385 | 1730 | 2076 | |
Cooling water Lit | 432 | 865 | 1728 | 2595 | 3456 | 4320 | 5190 | |
Dimension | L | 4806 | 4806 | 4806 | 4806 | 5106 | 5106 | 5106 |
W | 3088 | 3341 | 5022 | 6862 | 8732 | 10602 | 12572 | |
H | 3071 | 3071 | 3071 | 3071 | 3071 | 3071 | 3071 | |
Why Choose us ?
1.We are the professional factory of dyeing machine in Jiangsu Province ,China .
2.Quality Control through the whole Manufacturing process.
3.General Inspection on fixing before Packing.
4.Our hardware all passed ISO 9001 and ISO14001
